Smart lock

graffiti scheme

1. Unlock method: fingerprint, password, Tuya Bluetooth,Temporary password, five unlocking methods with mechanical key.

2. The number of fingerprint groups: 50, the number of password groups: 40 groups,Number of Bluetooth groups: unlimited.

3. Wiring-free structure, no power cord connection between the front and rear handles.

4. All-metal modular clutch structure,High quality motor drive principle,Safer than solenoid actuated principle clutches.The wiring-free structure is more convenient to install,The modular structure makes the product more stable and reliable.

5. Standard 1000mAh rechargeable lithium battery,It can last 1500 times on a single charge.

6. Human voice navigation.

7. Normally open mode selection.

8. Switch between Chinese and English.

9. Optional Tuya Bluetooth gateway for remote unlocking.

10. Optional double-sided fingerprint unlocking configuration.

11. Standard new 5050 double fast fake mortise lock body(Liner size: 147*22MM),,160MM,165MM,170MM,175MM,180MM, 190MM, 200MM liner length optional.

12. Handle material: zinc alloy, panel material: stainless steel.

13. Suitable door thickness: 38-55MM (please explain if the door thickness exceeds the range).

14. Panel size: 220MM*50MM, thickness 1.2MM,Equipped with adjustable hole distance bottom plate,Suitable for 110MM-190MM screw hole distance mechanical lock panel replacement;

15. The handle has an emergency lock cylinder,It can be used for both emergency unlocking and mechanical forced recovery to factory settings.
